RBGESP

Data Sheet RBGESP

✅ Product code RBGESP

✅ Interface connections RJ45 Male/Female Connector

✅ ESD/EMP protection Absorbing transient current with response to surge voltage of 100 V/s 1 kV/μs

✅ ESD, IEC 61000-4-2, ±30 kV contact, ±30 kV air

✅ DC spark-over voltage 90 V @ 100 V/s

✅ Maximum impulse

✅ spark-over voltage 700 V @ 1 kV/μs

✅ Discgarge current 5 kA (8/20μs)

✅ Minimum insulation

✅ resistance 1 G ohm @ 50V

✅ Maximum capacitance 4 pF @ 1 MHz

✅ Data line protecion RJ45 10/100/1000 Ethernet

✅ PoE support Yes, IEEE 802af/at

✅ Operating temperature -40 to 70°C
