Model

RG-ES05

Ports

5 10/100M Base-T ports

Operating mode

Half-duplex, full-duplex, auto-negotiation mode

Support auto MDI/MDIX

Backplane bandwidth

1Gbps

Packet forwarding rate

0.744Mpps

MAC address

1K

Power supply

External, DC 5.0V / 600mA

Maximum power consumption

≤2.5W

Fan

Fanless

Dimensions

108.1mm*64mm*24.8mm

Temperature

Operating temperature: 0 ℃ ~ 40 ℃

Storage temperature: -40 ℃ ~ 70 ℃

Humidity

Operating humidity: 10% ~ 90% RH

Storage humidity: 5% ~ 95% RH
