Hardware Specifications

Wireless Standards

IEEE 802.11 ac/n/b/g/a

Operating Bands

2.4GHz & 5GHz

Spatial Streams

2.4GHz: 2x2 MIMO  5GHz: 2x2 MIMO

Antenna

2.4GHz: 5dBi, 5GHz: 5dBi

Signal Rate

Up to 300 Mbps at 2.4GHz

Up to 867 Mbps at 5GHz

Maximum Transmit Power

2.4GHz: ≤24dbm

5GHz: ≤26dbm

Maximum Power Consumption

< 13W

Interface

(1)10/100/1000M Base-T LAN Ethernet ports

Power Supply

802.3af/at PoE Supported

Weatherproof Enclosure

IP65

ESD Protection

6KV

Mounting

Pole Mounting (Kits included)

Buttons

reset button (long press for 8 seconds

to restore the factory default configuration)

Dimensions

160mm * 170mm

Environment

Operating Temperature: -40°C～60°C

Storage Temperature: -40°C～70°C

Operating Humidity: 5% ～ 95% (non-condensing)

Storage Humidity: 5% ～ 95% (non-condensing)

Software Features

Operating Mode

Router Mode and AP Mode

Internet Connection Type

Static IP, DHCP, PPPoE Dial-Up

Network Security

Guest Wi-Fi； Hide SSID； Wi-Fi Isolate

Parental Control; IP/MAC binding

Wireless Security: WPA-PSK/WPA2-PSK/WPA3-SAE

Advanced Features

Mesh: Supports zero-configuration networking of multiple devices, and supports automatic switching between wired and wireless networking for multiple devices.

Wi-Fi optimization: Wi-Fi roaming, channel adjustment, power adjustment

Firewall: Forbid TCP/UDP flood attack

Application: Port Forwarding; SD-LAN; Open VPN;

Software upgrade: Firmware upgrade online or

Firmware upgradeable via browser

Diagnostics Utilities: Ping; IPV4 Traceroute; Nslookup

Management and

Maintenance

Support local management with web

Support remote management with the Wi-Tek Cloud platform
